Saturday, June 9, 2018

Friedrichshafen 2018





Friedrichshafen 2018 is over. Again, thanks a lot to everyone for visit! Year after year there is more and more friends :) There are some photos:

Tables and Paul A65DR, friend from A44A!

Mike DM5XX/OK8XX and Tibi OM3RM
BIG-GUNs: Masaru JA5AQC, Pavel OK1MY and guys from D4C:
Andrea HB9DUR, Luca IK2NCJ and Antonio CT1DVV
Friends from Italy, thanks Francesco IZ7KHR and
remote controlled Andrea with great EX Vodka!!!
Camp: beer with Antonio CT1DVV and our BBQ :)
Local paradise (19°C)


Better than QSL :D

Some links:
Francesco IZ7KHR
Christoph

What to say more, all the best to you, and see you next year close to Bodensee!

Thursday, June 7, 2018

CQ WPX RTTY 2018 OK6W SOAB - results





NEW EU RECORD!
- the highest number of MULTs ever!
- higher score in SOAB (36h) than in MS (48h)
- great fun with SO2R :)








Thursday, May 24, 2018

RTL-SDR dongle with new TCXO oscillator

RTL-SDR (RTL2832) is very cheap TV dongle than can be used as PC based scanner. You can use it for various applications as: HF/VHF/UHF SDR receiver, waterfall for your TRX (IF), APRS Igate, ADS-B Aircraft radar etc.

Dongles use classic 28.8 MHz crystal oscillator. With original one the frequency stability and error is quite poor. Frequency mistake is around 15 kHz on 900 MHz...

That is why I decided to try to exchange original oscillator for the NEW 28.8 MHz TCXO with 0,5ppm. There are some pictures of the modification.

TCXO informations


Frequency offset with original crystal oscillator:

And with NEW TCXO installed!

Remove original crystal

Clean piece of GND on PCB and solder TCXO.
Be careful! Do not connect top of the TCXO with the ground!!!
Cu wire from crystal pad to TCXO one.
Cu wire from Vcc to the TCXO with additional capacitor.
Or another possibility:

Example of application of RTL-SDR with great open sw OpenWEB RX:
- 10 GHz SDR RX with SAT LNBs with TXCO :)


Thursday, May 3, 2018

Spring is here ! And new 6/4m 13el Yagi





Thanks to the public holiday we did have four days weekend :) After some month Mike DM5XX/OK8XX came again to see us and enjoy the Policko QTH. There has been really nice WX last days and weeks so we needed to cut the green too. It took almost 3 days!

I spent one day with antenna building. I do have nice design for 6 and 4 meters antenna on one boom from Popa YU7EF. Antenna is placed on the temporary place and waiting for JA condx :)

I have also played with new Raspberry PI on TWR7 in 38m. It works as webcam, 2m APRS I-gate and soon also as 10GHz public webRX.


Feed point of 4/6m Yagi











Temporary palce for 4/6m 13el Yagi, under 10m one.
